West Mountain Radio PWRcheck+, DC power analyzer, watt meter, with logging plus software via USB

Hardware

• Handles 8 display modes including voltage, current flow in either direction, wattage and amp-hours
• Measures 0V* to 60V (Less than 8V requires USB power to PWRcheck+), 40A continuous load
• Accurate to within +/- 10mV, +/- 10mA
• Resolution - 10mV, 10mA
• High side monitoring does not require breaking power supply ground or return path, ideal for vehicle use
• Vibrant LCD color touchscreen displays data in digital, analog and bar graph formats
• Monitor back up battery with programmable gas gauge
• Non-volatile memory stores more than 100,000 data points (nearly 2 1/2 months worth of data @ 1 point per minute) without power
• USB computer interface for configuration and data download
• Programmable alarm conditions for overcurrent, over/under voltage, amp-hours
• Uses Powerpole connectors (see Accessories)
• Dimensions: 0.875" H x 4.5" W x 3" D

Software

• Easily program every aspect of PWRcheck+ operation such as data logging rate, display formats, alarm conditions
• Displays current, voltage, wattage and amp-hours in real time
• Integrated charting software automatically collects and displays data
• Downloads stored data for later analysis
• Exports to Excel

Specifications

• Input Voltage Without USB: 7-60V
• Input Voltage With USB: 0-60V
• Input Current: 0-40A
• Input Current Used by PWRcheck+ Without USB: 0.120A
• Input Current Used by PWRcheck+ With USB: 0A
• PWRcheck+ requires a minimum 50mA load to measure voltages below 4.5V.

Includes

• PWRcheck+ - integrated DC power analyzer, watt meter and electricity monitor
• PWRcheck software
• Micro USB cable
• 2 pair Red and Black Powerpole with 30A contacts
• Owner's Manual

Basic Requirements

• At least an 800 X 600 graphics card and display monitor
• Windows XP, Vista: 32 or 64 bit, Windows 7: 32 or 64 bit, Windows 8, Windows 10
• An available USB port
