Bluetooth Smart built-in
The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.
For a wired data connection to a Color Control GX, other GX products, PC or other devices
Ultrafast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.
Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%. The full output current up to 40°C (104°F).
Flexible charge algorithm
Fully programmable charge algorithm (see the software page on our website), and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details).
Extensive electronic protection
Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection.
Internal temperature sensor
Compensates absorption and float charge voltage for temperature.
Optional external battery voltage and temperature sensing via Bluetooth
A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers.
Fully discharged battery recovery function
Will initiate charging even if the battery has been discharged to zero volts. Will reconnect to a fully discharged Li-ion battery with integrated disconnect function.
Battery Voltage: 12/24V Auto Select
Rated Charge Current: 30A
Nominal PV Power - 12V: 440W
Nominal PV Power - 24V: 880W
Maximum PV Open Circuit Voltage: 100V
Max. PV Short Circuit Current: 35A
Maximum Efficiency: 98%
Self-Consumption 12V: 30 mA / 24V: 20 mA
Charge Voltage - Absorption: 14.4V / 28.8V (adjustable)
Charge Voltage - Float: 13.8V / 27.6V (adjustable)
Charge Algorithm: multi-stage adaptive
Temperature Compensation: -16 mV / °C resp. -32 mV / °C
Protection: PV reverse polarity; Output short circuit; Over temperature
Operating Temperature: -22 to +40°F - full rated outputup to 104°F (-30 to +60°C - full rated output up to 40°C)
Humidity: 95%, non-condensing
Data Communication Port: VE.Direct
Power Terminals: 6AWG (16 mm²)
Protection Category: IP43 (electronic components), IP22 (connection area)
Dimensions (h x w x d): 5.1 x 7.3 x 2.7 in (130 x 186 x 70 mm)
Safety: EN/IEC 62109-1, UL 1741, CSA C22.2
