Picture of Interchangeable accessory die sets for the TRIcrimp powerpole crimping tool
Interchangeable accessory die sets for the TRIcrimp powerpole crimping tool
  • $59.99
  • In Stock
  • SKU: TRIDIES

Interchangeable accessory die sets for the TRIcrimp powerpole crimping tool

Expand the functionality of your TRIcrimp tool with these additional die sets. Easily crimp OEM-T, HF/VHF connectors, SB50/PP75 contacts, hex crimp for various coaxial cable connectors, non-insulated terminals, insulated terminals, end sleeves and more. Read Full Description
$59.99
Availability: In Stock
SKU: TRIDIES
GTIN: 840128904398

The die sets are not endorsed by Anderson Power Products®. Only official tooling solutions recommended by APP may be acceptable for safety agency approvals such as UL, CSA and TUV. Official tooling solutions such as the 1309 series are available for purchase at a higher price.

This 6 die set package contains 6 Interchangeable accessory die sets for the TRIcrimp tool listed blelow.

TRIcrimp die sets will not fit or work with any other brand of tool.

D-OEM
This die performs the same function as our separate CT-OEM tool but configured to fit the TRIcrimp handle. Crimper designed for OEM-T power source and radio side connectors. Also works with other OEM HF/VHF connector contacts (Powerwerx SKUs: HF2, HF3, HF4, HF6 and mating radio side contacts).

D-75
This die performs the same function as our separate CT-75 tool but configured to fit the TRIcrimp handle. Crimper for 75 amp Powerpole and 50 amp SB Series contact numbers 5900 and 5952. Recommended for 6 and 8 gauge contacts. Can also be used for large solderless terminals.

D-HEX
Hex crimp tool for crimping various sizes of Coaxial cable connectors. The dies can work with but not limited to: RG- 58, 59, 62, 5, 6, 21, 140, 141, 142, 143, 210, 222, 223, 303, 304, Belden 8279, 8281, 9231, 9141

D-177
Non-insulated terminals from 7 AWG to 17 AWG dies custom made to fit the TRIcrimp handle.

D-1020
Excellent for Insulated terminals from 10 AWG to 20 AWG dies custom made to fit the TRIcrimp handle.

D-2213
Excellent for Insulated terminals and end sleeves from 10 AWG- 22 AWG custom made to fit the TRIcrimp handle.

TRIcrimp® is a registered trademark of Powerwerx. Powerpole® and SB® are registered trademarks of Anderson Power Products, Inc.

Customer Reviews
Decent Quality, Worthwhile If You Need Them All By
The TRIcrimp tool itself is good for PowerPoles, love it for that.  This kit of dies is decent quality, the casting and finishing are slightly better than is typically found for mid-grade tools like this.  Of course they're not production Tyco/Ideal/Molex/Delphi level quality and precision but they don't come with the price tag either.  The dies themselves are worth the price if you need enough of them to justify the kit price.

The only dies I have an issue with are the D-HEX.  It would be helpful if the D-HEX had dimensions cast in since it was a bit of trial and error and measurements to figure out.  It appears on the 5 cavity set I got they are intended to be as follows.

0.324" (8.1mm)
0.255" (6.5mm)
0.213" (5.4mm)
0.100" (2.6mm)
0.068" (1.72mm)

This means you won't have at least  0.052" (1.3mm), 0.178" (4.5mm) and 0.429" (10.8mm), which are some other common sizes you'll come across.  D-HEX seems intended for RG-58 or RG-6 with F or UHF and will usually lack one you need for RG-174/316, RG-8/213, SMA, N, BNC.

But that's not unusual, it's simply not possible for one set of dies to cover everything after all and so you usually end up with more dies and tools anyway.  So like I say, my complaint is just the lack of markings so you know what you're using.
Was this review helpful? Yes No (38/0)
Extra Dies for the TRICrimp Tool. By
Wish you could purchase TRICrimp Dies in singles and not have to buy entire set just to get the one you want. West mountain Radio sells them in singles. I just hate to have to order from two different stores to get what I need. Fred
Was this review helpful? Yes No (45/5)
Smart buy By
I've used this over a year now and am very pleased with the purchase. You'll find that you can crimp all manor of things with these with a little trial and error such as the M4 connectors that many solar companies now use.
Was this review helpful? Yes No (16/0)
Good Deal By
This is a good deal vrs purchasing individual crimpers. I recently retired and can no longer sign out tools from the shop. After pricing the crimpers I need for the various cables I am always building as a ham This will save me significant $$. The quality of the dies is good and are easy to swap in the handle. Just remember to adjust the tension
Was this review helpful? Yes No (60/2)
