Picture of Mastervolt 83304002 Charge Mate Pro 40 Automatic Charging Relay 40 Amp
Mastervolt 83304002 Charge Mate Pro 40 Automatic Charging Relay 40 Amp
  • $214.99
  • In Stock
  • SKU: 83304002

Mastervolt 83304002 Charge Mate Pro 40 Automatic Charging Relay 40 Amp

Designed to distribute the charger or alternator current effectively between two battery banks such as a starter and a service battery. Connects both batteries during charging and keeps them isolated when discharging. Limits charging of secondary/auxiliary battery to 40 amps. Read Full Description
$214.99
Availability: In Stock
SKU: 83304002
GTIN: 852968002981

Current limited electronic charge relay with high efficiency and reverse current protection. A secondary battery on board requires a dedicated charging solution. The Charge Mate pro 40 connects both battery banks during charging and keeps them isolated when discharging This significantly reduces the risk of a flat starter battery. Suitable for all battery types, including Lithium Ion Phosphate.

Features:

  • For controlled charging from a single source
  • Charge second/auxiliary battery limited to 40A
  • Electronic charge coupling with very low voltage drop
  • High system reliability by prioritized charging of the main battery
  • Prevents power dips of the onboard electrical network
  • IP65 electronics in a corrosion resistant casing with aluminum heat sinks
  • Simple installation

Specifications:

  • Output Current: Limited to 40A
  • Input Voltage Range: 9-32 VDC
  • Battery Voltage: Auto Detect 12/24 VDC Systems
  • Switch ON Voltage: 13.5 VDC (12V) / 27.0 VDC (24V)
  • Switch ON Delay: 5 seconds
  • Switch OFF Voltage: 12.75 VDC (12V) / 25.5 VDC (24V)
  • Switch OFF Delay: 2.5 seconds
  • Relay: Electronically (Mosfets with low voltage drop of maximum 0.2 VDC)
  • Temperature Range: -40 F to 140 F
  • Protection degree: IP65
  • Approvals: CE
  • Size: 6.2" W x 5.5" H x 3.1" D
Environmental & Legislation

RoHS Compliant: Yes
